Concept Fumehood

Fisher Scientific’s fume hoods meet the requirement of the UL 1805 classifications. Tested and certified according to ANSI/ASHRAE 110 (1995); NFPA, OSHA, ACGIH, ANSI/AIHA compliance and SEFA 1 compliance

Concept is the first fume hood to incorporate AutoSash™ technology to maximize the safety and energy savings through proper sash positioning.

Concept have a “low flow” design, capable of proper containment at lower (60 FPM) face velocities. These hoods provide a higher visual sight line, chain & sprocket counterbalance, and a flush sill/trough to enhance safety and comfort.

Concept fume hoods are available in both bench and floor-mounted models.
Concept  Feature
  • 35" sash viewing height provides improved viewing
  • Thermo Scientific Hamilton AutoSash® automatic sash positioning system locates the sash for face and upper body protection.
  • The sash locks in the setup position and automatically returns to the maximum operational height when the lock is released.
  • Improved combination sash provides comfortable access at the work surface. Air flows through the bypass area with increased volume and less resistance for quieter operation.
  • Low profile airfoil ergonomically designed to provide obstruction free access to the hood interior.
  • Secondary trough is additional safeguard for the containment of spills not secured by a dished  work surface
  • Chain and Sprocket drive sash counterbalance system
  • Preset baffle system – no adjustment required
  • 60 to 100 FPM face velocities
  • Steel frame structure , Polyurethane coated steel panels
  • Polyresin interior liner: flexible strength 14000psi (960bar); fire retardant – meets US NFPA 45; chemical resistant
  • Moulded Epoxy worktop with dished sides to prevent spill
  • No metal parts inside hoods, not even covered stainless steel screws
  • Laminated tempered glass for sash
